’96 IMABARI JAPAN 3,773.45DWT TWEEN DECK CARGOSHIP FOR
SALE.
Ships Particular
1. Name of Ship : DONGJIN KOBE ( )
2. Flag : KOREA
3. Port of Registry : JEJU
4. Official Number : JJR-121037
5. I.M.O Number : 9153848
6. Call Sign : D7LP
7. Kind of Ship : Motor Vessel
8. Type of Ship : Cargo Ship
9. Owner : DONGJIN SHIPPING CO. LTD
10. Operator : DONGJIN SHIPPING CO. LTD
11. Tonnage : Gross : 2,921 (ITC) / 2,605 (Registry) : Net : 1,383
12. Dead Weight : 3,773.45 Ton
13. Length : 83.75M / 78.68 M
14. Breadth : 14.50 M
15. Depth : 9.20 M
16. Freeboard : Tropical : 93 mm
From Deck : Winter : 341 mm
Line : Summer : 217 mm
17. Speed : Design Speed : 11.30 Kts Max Speed. at sea Trial : 14.22
Kts
18. Date of Launch : 1996. 08. 02 Keel Laid : 1996. 06. 11 Built :
1996.
09. 30
19. Name of Builder : IMAMURA SHIPBUILDING CO. LTD. Japan
20. Main Engine : AKASAKA A-37, 2600PS(1912KW) X 250RPM
21. Hold (M) : No 1 Hold : 10.5m(L) X 10.2m(W) X 7.8m (Coaming H.
1.7m)
No 2 Hold : 25.2m(L) X 10.2m(W) X 7.8m (Coaming H. 1.7m)
22. Dynamo Engine : Yanmar 6HAL-HTN Output and Revolution :
270PS(199KW) X
1800 rpm
23. Kind of Fuel : MF-150 Diesel Oil : Gas Oil
24. Fuel Consumption : 139 g/PS/h (at MCR) 188.99 g/KW/h
25. F.O Capacity : No 1 F.O (111.4 ), No 2 F.O P&S (85.8 ) Total :
283.00
26. D.O Capacity : No 3 D.O P(23.80) No 3 D.O S(23.50) Total : 47.43
27. Ballast Capacity : 848.76
28. Container(In Hold, On Deck)
29. Classification : KOREAN REGISTER OF SHIPPING (KR) SS Sept 2016 DD
Aug
2016
30. Number of Crew : 15 person
31. Navigation Area : Coastal
32. Cargo Capacity : Bale : 6,326 Grain : 6,586
33. Cargo Gear(Derrick System) : 20 Ton X 2(No 1&3) 30 Ton X 1(No 2)
34. Inmarsat-C No : 444086110
35. Tel / Fax No : 773-190-946 / 783-194-946
36. Others. Fresh W. T: 217.21 (4tanks)
37. Strength : No 1 Hold - 6.0 ton/, No 2 Hold - 9.7 ton/ 2nd deck:
2.5
ton/
Main Engine
Engine Type. No : A37, 1138 IMAMURA SHIPBUILDING CO. LTD
MCR : 2600 PS (1912KW) X 250RPM X 6Cyl Normal : 2210PS(1625Kw) X
237RPM
Cyl bore & Stroke : 370mm X 720mm
Firing Order : 1-3-5-6-4-2
Fuel Consumption : 139 g/PS/h (at MCR)
Turbo-charger : MET 30SR type ( 29400 RPM )
Air Cooler : Shell and tube with fin type 4.2 (tube) 81.0 (with fin)
S/B L.O Pump : Gear type, 40/h X 5 kg/, 15kw X 1200 rpm
Cool. S.W Pump : centrifugal type, 80/h X 20m, 11kw X 1800 rpm
Cool. F.W Pump : centrifugal type, 45/h X 20m, 5.5kw X 1800 rpm
F.O Supply Pump : Gear type, 1/h X 5.5 kg/, 0.75kw X 1200 rpm
Propeller
4 Blade Fixed Pitch Propeller. 2900mm Dia X 1815mm Pitch X 1set
Generator Engine
Engine Type : Yanmar 6HAL-HTN Serial No : 22630, 22631
Output and Revolution : 270PS X 1800 rpm
No of Cyl, Bore and Stroke : 6 X 130mm X 150mm
: By Electric Cell Motor
: 240 kg/ : 1-4-2-6-3-5
: 50% : 23.0 kg/h 75% : 31.3 kg/h 100% : 41.1 kg/h
F.W Cooler : 15 RI-80 L.O Cooler : 30 RI-100
MAIN AIR COMPRESSOR L-Type 2Stage Air Cooled (L 2 )
Model : MG95A : 108mm : 60mm 1160 RPM
Capacity : F.A 32.5 /hr : 10 (7.5KW)
50.9 /h X 30 Kg/ X 2set (MATSUBARA MG95ADT)
HOT WATER BOILER
Vertical Oil Fired water Tube Boiler : 19000 Kcal/h X 1set (MIURA
HV-20)
EMERGENCY FIRE PUMP
15PS Diesel Engine Driven Emergency Fire Pump : 35/h X 50m X 1set
ELECTRIC PART
MAIN GENERATOR : Drif-proof, Self-ventilated Type AC-445V, 225KVA X
2set(TAIYO)
Magnetic Compass : Projector Type X 1 set (DAIKO KEIKI SP-165PDK)
Gyro Compass and Repeater : Master gyro compass X 1, Repeater X 6
(TOKIMEC
TG-6000)
Radar : 20" X 25kw X 120N. mile X 2sets (FURUNO FR-2120-3A)
Doppler log : 1set (TOKIMEC TD-201)
Echo Sounder : 1set (FURUNO FE-680T-1)
Air horn : 1set (IZUMITATSU A200H)
Wind indicator : 1set (NIPPON ELEC. INSTR. N-54)
GPS Navigator : 1set (FURUNO GP-500)
Facsimile Receiver : 1set (FURUNO FAX-210)
Navtex Receiver : 1set (FURUNO NX-500)
VHF Radio Telephone : 2set (FURUNO FM-8500)
Satellite EPIRB : 1set (FURUNO KANNAD 406FH)
Radar Transponder : 2 sets (FURUNO TBR-200)
Two way VHF Radio Telephone : 3sets (FURUNO FM-8)
Radio Rack Console : 1set (FURUNO RC-2000-3F)
Distress Message Controller : 1set (FURUNO DMC-5)
DECK MACHINERY AND EQUIPMENT
Cargo Gear Winch
-Cargo Winch : Hydraulic Motor Driven 7.5T X 30m/min X 3sets
-Topping Winch : Hydraulic Motor Driven 7.5T X 30m/min X 3sets
-Guy Winch : Hydraulic Motor Driven 7.5T X 30m/min X 3sets
-Power Unit : 75 kw X 1170rpm X 3sets
Windlass
-Hydraulic Motor Driven 10/5T X 12/24m/min X 2sets
Mooring Winch
-Hydraulic Motor Driven 5/2.5T X 15/30m/min X 2sets
Steering Gear
-Electro-Hydraulic System 8.5T-m With Auto Pilot X 1set
-Power Unit 5.5 kw X 1750rpm X 2sets
(All details about wog)
TRADING: BUSAN, KOREA - JAPAN
